Automotive ethernet
Trigger & decode oscilloscope software package
The R&S®RTP and R&S®RTO oscilloscope supports serial triggering and decoding of 100BASE-T1 or BroadR-Reach and 1000BASE-T1 Automotive Ethernet standards. Efficiently trigger on frame start, Idle frames, MAC frames including destination & source address, frame types and on various error conditions. The MXO 4 series support 10BASE-T1S and MXO 5 series support both 10BASE-T1S and 100BASE-T1 decoding.
Features:
- Trigger and decode of 10BASE-T1S, 100BASE-T1/BroadR-Reach® and 1000BASE-T1 automotive Ethernet buses
- Colour coded bus display with details down to ternary symbols
- Full decode table with all details
- Powerful trigger and search capability
- Fast eye-diagram mask testing with up to 600.000 waveforms/secs
